MODUflex "Coaxial"

 Rebreathing and non rebreathing animal applications

The Moduflex "Coaxial" anesthesia machine is the first ever to incorporate a CO2 absorber with an integrated "Coaxial" breathing circuit. This reduces patient heat loss, helps to humidify the inspired gas and reduces hose clutter.

The function of a Coaxial circuit is to deliver fresh gas to the patient via an inner tube, surrounded by the exhaled, warmed and humidified waste gases which are then returned to the absorber and exhausted through an evacuation port.


  • 1500cc heavy duty "Coaxial" absorber, recessed. Canister is molded and will never separate from it's base sealing ring.
  • Single large thumbscrew canister release
  • .1 to 4lpm precision Oxygen flowmeter
  • Rotary float and large scale for improved readability
  • Recessed flush valve to prevent accidental activation
  • Quick connect fresh gas outlet for easy and secure switching between breathing circuits
  • Selectatec compatibility manifold for easy and quick installation of any model Vaporizer
  • Large Quick Lock Inspiration and Expiration domes for easy access and visibility
  • Instrument shelf, stainless steel 8" x 12"

Momentary closed feature incorporated into our pop-off valve
. This new feature assists in the quick bagging of a patient, without having to remember to reset the pop off valve to it's previous position. Just push and hold the button, and when bagging is completed remove your finger from the button. Great safety feature (Also available as a retrofit for all older models of Moduflex Anesthesia Machines)

  • Circuit presure gauge, easy to read and large
  • Rotating bag mount for ease of visibility and easy access
  • 19mm built in Evacuation connector in rear
  • Frame finished with textured powder coat for long life
  • High stability 16 gauge construction
  • Large heavy duty 4" cushioned castors,2 with locks, for easy glide and long life
  • Pre tapped holes for easy installation of bain circuit adaptor and scavenger interface
  • Oxygen supply hose 9ft
  • Patient circuit with 2 and 3 L bags
  • Length 21", Width 19.5", Height 53", Weight 57 lbs
  • 5 Minute assembly by a novice
  • 5 Year warranty


  • Vaporizer
  • Dual Selectatec manifold for installation of two vaporizers and safety interlock
  • Drawer module 4 drawers
  • Larger Monitor shelf 11" x 13.5"
  • Scavenger interface
  • Bain circuit adaptor
  • Ventilator
  • Preset regulator
  • E Cylinder kit
  • N2O Kit
(Trade ins welcome)
